Analysis of Ca⁺⁺-dependent gain changes in PDE activation in vertebrate rod phototransduction

Russell D. Hamer



Smith-Kettlewell Eye Research Institute, San Francisco, CA

Correspondence to: Russell D. Hamer, Smith-Kettlewell Eye Research Institute, 2318 Fillmore Street, San Francisco, CA, 94115; Phone: (415) 345-2056; email: russ@ski.org

Abstract

Purpose: Recent biochemical and physiological data point to the existence of one or more Ca⁺⁺-mediated feedback mechanisms modulating gain at stages early in the vertebrate phototransduction cascade, i.e., prior to activation of cGMP-phosphodiesterase (PDE). The present study is a computational analysis that combines quantitative optimization to key data with a qualitative evaluation of each candidate model's ability to capture "signature" features of representative rod responses obtained under a broad range of dark- (DA) and light-adapted (LA) conditions. The primary data motivating the analyses were the two-flash data of Murnick & Lamb. These data exhibited strikingly nonlinear behavior: the period of complete photocurrent saturation (T_sat) in response to a Test flash was reduced substantially when preceded by a less-intense saturating Pre-flash. Depending on the delay between Pre- and Test flashes, the change in T_sat (ΔT_sat) could exceed the magnitude of the delay, and could be reduced by as much as ~50%, corresponding to a large reduction in gain by a factor of 10-15. The overall goal of the study was to evaluate what model structure(s) were commensurate with both the Murnick & Lamb data and the salient qualitative features of rod responses obtained under a broad range of DA and LA conditions.

Methods: Three candidate models were quantitatively optimized to the Murnick & Lamb saturated toad rod flash responses and, simultaneously, to a set of sub-saturated flash responses. Using the parameters from these optimizations, each candidate model was then used to simulate a suite of DA and LA responses.

Results: The analyses showed that: (1) Within the context of a model with Ca⁺⁺ feedback onto rhodopsin (R*) lifetime (τ_R), the salient features of the Murnick & Lamb data can only be accounted for if the rate-limiting step is not the Ca⁺⁺-sensitive step in the early cascade reactions, i.e., if PDE* lifetime, and not τ_R, is rate-limiting. (2) With τ_R rate-limiting, the model cannot account for ΔT_sat exceeding the delay. (3) The Ca⁺⁺-dependent reduction in τ_R required to effect the large gain is incommensurate with the empirical dynamics of dim-flash responses. (4) Regardless of which reaction is rate-limiting, a model using solely modulation of R* lifetime puts strong constraints on the domain of biochemical parameters commensurate with the large gain changes Murnick & Lamb observed. (5) The analyses show that, in principle, the Murnick & Lamb data can be accounted for when τ_R is both rate-limiting and Ca⁺⁺-sensitive if, in addition to the feedback onto τ_R, there is an earlier, stronger Ca⁺⁺ feedback that does not affect R* inactivation kinetics (e.g., gain at R* activation or transducin (T*) activation). (6) Ca⁺⁺-modulation of R* activation or T* activation as the sole early gain mechanism can also account for the Murnick & Lamb data, but fails to predict the data of Matthews, and can thus be rejected along with any model of comparable form.

Conclusions: The results imply that the Murnick & Lamb data per se are insufficient to rule out rate-limitation by (Ca⁺⁺-sensitive) R* lifetime; evaluation of a broader set of responses is required. The analyses illustrate the importance of evaluating candidate models in relation to sets of data obtained under the broadest possible range of DA and LA conditions. The analyses are aided by the presence of reproducible signature, qualitative features in the data since these tend to constrain the domain of acceptable model structures and/or parameter sets. Some implications for vertebrate photoreceptor light-adaptation are discussed.

Introduction

A recent paper by Murnick & Lamb [1] presented physiological data with striking nonlinear features. Using a two-flash technique, the authors found that a saturating Pre-flash applied to toad rods dramatically reduced the period of complete photocurrent saturation (T_sat) elicited by a second, more intense, saturating Test flash. The interpretation of the data was that the Pre-flash led to a Ca⁺⁺-dependent reduction in gain early in the phototransduction cascade. The effective gain reduction was substantial. T_sat for the Test flash was reduced by as much as 6-7 s by the Pre-flash, corresponding to an effective reduction in gain by a factor of 10-15, depending on the slope of the T_sat versus ln(I) function. This interpretation receives support from several lines of recent experimental evidence that suggest that one or more steps in the biochemical events leading to activation of cGMP-phosphodiesterase (PDE*) are regulated dynamically by the level of internal calcium [1-11].

The authors suggest that the observed decreases in Test flash T_sat could result from Ca⁺⁺-sensitive gain modulation at an early phototransduction step. They propose that the Ca⁺⁺-sensitive process could be Ca⁺⁺-modulation of the rate of rhodopsin (R*)-inactivation (R* phosphorylation). In this model, a decrease in internal Ca⁺⁺ pursuant to a flash of light (and cGMP-gated channel closure) accelerates the process of phosphorylation of R* by releasing rhodopsin kinase (RK) from inhibition by the Ca⁺⁺-binding protein, recoverin (Rec) [4-9].

Murnick & Lamb [1] propose that their data are consistent with PDE*-inactivation being the rate-limiting step in photocurrent recovery, not R* inactivation as proposed by Pepperberg et al. [12-14]. In this model, R* lifetime would be significantly shorter than PDE* lifetime, and would decrease further with light-induced decreases in internal Ca⁺⁺, reducing the effective gain of photocurrent activation without altering the overall dynamics of photocurrent recovery from saturation controlled by the slower PDE*-recovery. The critical observation supporting this interpretation of the data was that the decrease in T_sat was found to exceed the delay, Δt, between Pre- and Testflashes (e.g., for Δt = 1 s, T_sat was typically reduced by 2 s). Murnick & Lamb reason that within a RecRK model structure, if the light-induced gain reduction is generated at the same step that forms the rate-limiting reaction, this predicts a decrease in T_sat that is, at most, equal to, but never greater than Δt.

Goals of the Present Study

The present article implements and evaluates the model structure (the RecRK model) suggested by Murnick & Lamb [1] to explain their data. In addition, two other candidate models are analyzed. The first alternative model has an early gain mechanism that does not alter the dynamic of photocurrent recovery, i.e., Ca⁺⁺-modulation of effective R* catalytic gain without a concomitant modulation of R* lifetime (R* activation model). This corresponds to an implementation of a scheme proposed by Lagnado & Baylor [2] to explain their observations that, during the period of light exposure, experimental reduction of Ca⁺⁺ caused a substantial decrease in transduction gain, but no apparent change in response kinetics. The second alternative model combines the two early gain mechanisms, R* lifetime (RecRK) and R* activation (RecRK-R* activation model).

The models were evaluated in relation to the Murnick & Lamb data, as well as in relation to other key data obtained under a broad range of stimulus conditions. The approach was similar to that used in Hamer [15], i.e., a combination of quantitative optimization of the models to one or more sets of data, combined with qualitative evaluation in which the optimal parameters are used to predict signature qualitative features of a suite of data sets from other experiments under both dark-adapted (DA) and light-adapted (LA) conditions.

The overall goal of the study was to evaluate what model structure(s) are commensurate with both the Murnick & Lamb data and the broader suite of representative DA and LA rod data. The analyses confirm that, within the context of a RecRK model structure in which R* lifetime is Ca⁺⁺-sensitive, PDE* lifetime indeed must be rate-limiting in order to account for all the features of the Murnick & Lamb data. In addition, the analyses show that rate-limitation by R* lifetime in a RecRK model imposes other fundamental constraints: with τ_R rate-limiting, the change in τ_R required to reproduce both the observed gain changes (10-15x) and the empirical intensity-dependence of T_sat [1,12-14] is incommensurate with the dynamics of dim-flash responses. Moreover, it is shown that, if the large gain change implied by the Murnick & Lamb data (10-15x) occurs entirely by means of modulation of R* lifetime, then severe constraints are imposed on some key biochemical parameters and that these constraints occur regardless of which is the rate-limiting inactivation reaction, R* or PDE* lifetime.

The analyses demonstrate that the Murnick & Lamb data can be accounted for by a model in which R* lifetime is both rate-limiting and Ca⁺⁺-sensitive if, in addition to feedback via RecRK, an early, stronger feedback is present. However, this additional feedback must be such that it does not significantly alter the recovery kinetics of the rate-limiting reaction. This result implies that the Murnick & Lamb data alone are not sufficient to unequivocally identify the rate-limiting reaction in the early cGMP cascade.

Finally, the results show that some model structures can be ruled out despite the fact that they can provide an excellent account of the Murnick & Lamb data, since they fail to account for robust qualitative features of data from other experiments. The latter two results highlight the importance of including as broad a range of data as possible in model evaluation.

Methods

Analyses

The analyses were similar to those used in [15]. Candidate models were quantitatively optimized (Optimization Toolbox, The Mathworks, Natick, MA) to the Murnick & Lamb [1] saturated toad rod flash responses and, simultaneously, to a set of sub-saturated flash responses from Rieke & Baylor [16]. After the optimization, the optimal parameters were then used to simulate a suite of dark- and light-adapted empirical rod responses under a range of experimental conditions (Empirical Response Suites I and II, described below). The adequacy of each model was then evaluated based on quantitative (optimized) fits to the data, and on the ability of the model to capture salient qualitative ("signature") features of the broader suite of responses.

Inclusion of the sub-saturated flash response data in the initial optimization turned out to be crucial. Without it, the optimization was not adequately constrained, so that the model could achieve a good fit to the Murnick & Lamb saturated data with parameter values that failed to reproduce essential qualitative features of the Empirical Response Suite, including dim-flash responses and step responses. Inclusion of the sub-saturating responses constrained the optimization such that the model was then more likely to be able to reproduce signature features of the response suite.

Models

The candidate models each have four core sets of phototransduction reactions, elements of which have been implemented in a number of published models [15,17-20].

(1) Simplified R-, PDE activation scheme (Eqs. 1-3). PDE activation is modeled as two sequential first-order reactions [19-21]. In the scheme depicted by Eqs. 1-3, feedback from RecRK has been included (q₅RK* in Eqs. 1,2), plus a slow back-reaction from inactive R_i to R* (τ_b, τ_Ri in Eqs. 1,2; also see Eqs. A6-A8, Appendix 1). RK* in Eq. 1 represents the amount of activated rhodopsin kinase at time t. In Eq. 1, it acts to modulate the rate of R* inactivation. The effect of lowered Ca⁺⁺ (in response to light) is to increase RK*, increasing the rate of R* inactivation. Both the RecRK feedback reaction and the rhodopsin back-reaction are discussed in Appendix 1.

In Eqs. 1 and 2, (1/τ_b) and (1/τ_Ri) are the rate-constants for the back-reaction between R and R* and the disappearance of inactivated rhodopsin. q₅RK* is a pseudo-first-order rate constant for R* inactivation. Φ is the number of photoisomerizations elicited by a brief flash of light.

In Eq. 3, ν_rp is the rate of activation of PDE per rhodopsin molecule [20,21], and 1/τ_E is the rate constant of PDE*-inactivation (i.e., τ_E is the time constant of PDE*-inactivation).

(2) Dynamic Ca⁺⁺ reactions (Eqs. 4 and 5). Equations 4 and 5 describe Ca⁺⁺-influx through the light-sensitive cGMP-gated membrane cation channels (first term, Eq. 4), efflux via the Na⁺: Ca⁺⁺, K⁺ electrogenic exchanger (with rate γ_Ca; second term, Eq. 4), and dynamic Ca⁺⁺-buffering (c_b, third and fourth terms, Eq. 4 and Eq. 5; cf. [17] and [18]). In Eqs. 4 and 5, c is the concentration of free internal Ca⁺⁺ at time t, and c_b is the concentration of Ca⁺⁺ bound to buffer at time t. In the first term in Eq. 4, J_d is the dark circulating current, and F is the fraction of channels open at time t. The Ca⁺⁺-influx through the channels is set by the factor [F_Ca/(2F_fdV_cyto)], which gives fraction of current carried by Ca⁺⁺ (F_Ca), converted to concentration units (by the Faraday constant, F_fd, and the cell volume, V_cyto). The Ca⁺⁺-buffer binds Ca⁺⁺ with an on-rate of k₁, and an off-rate of k₂. The parameter e_T is the total buffer concentration.

(3) Hydrolysis and synthesis of cGMP (Eq. 6). PDE* hydrolyzes cGMP (second and third terms, Eq. 6), while Ca⁺⁺-modulates, in a cooperative fashion (with Hill coefficient, n_ca), the synthesis of cGMP by guanylate cyclase (A_max; first term, Eq. 6). The hydrolysis terms in Eq. 6 include a light-activated term (β_subE*(t)), and a term to account for basal hydrolysis of cGMP in the dark (β_dark; [17,18,20,21]). β_sub converts E* from a unitless number (of molecules) to units of concentration per unit time. K_ca is the concentration of Ca⁺⁺ that yields 1/2-maximal synthesis rate of cGMP (when c = K_Ca, the first term in Eq. 6 = A_max/2).

(4) Closure of membrane cation channels and generation of photocurrent (Eq. 7). The photocurrent elicited by a light stimulus is proportional to the number of membrane cation channels opened by the cooperative action (with Hill coefficient n_cg) of free cGMP (g).

To this core set of reactions two forms of additional Ca⁺⁺ feedback have been added, first singly, then in combination.

RecRK Model: This model introduces Ca⁺⁺-modulation of R* lifetime via RecRK (Eqs. 8,9). The model assumes a cooperative binding (with Hill coefficient, w) of free internal Ca⁺⁺ to Rec that happens rapidly in relation to the time scale of the other reactions. Hence, the interaction between Ca⁺⁺ and Rec is treated as if it was instantaneous and is quantified by the steady-state solution (Eq. 9) to the differential equations (Eq. A11, Appendix 1). In Eqs. 8,9 below, Rec* symbolizes Rec bound to w Ca⁺⁺ ions (see Appendix 1, Eqs. A9, A11, A12). K_Rec,Ca is the Ca⁺⁺ concentration at which half of Rec is bound to Ca⁺⁺.

Interaction between Rec* and RK (Eq. 8) is treated as a dynamic, reversible reaction. RK* is activated rhodopsin kinase, i.e., RK that has been released from inhibition by recoverin. The feedback gain control is established by an increase in RK* corresponding to a speed-up of the quenching of activated rhodopsin, i.e. an effective decrease in the time constant of recovery, τ_R. A decrease in Ca⁺⁺ pursuant to a flash of light (and cGMP-gated channel closure) decreases the amount of bound Rec- Ca⁺⁺, which reduces Rec's inhibition of RK, thus accelerating the process of phosphorylation of R* and ultimate capping (quenching) by arrestin [4-9]. Eqs. 8-9 are derived in Appendix 1, Section B.

The RecRK model is evaluated for two cases, τ_E and τ_R* rate-limiting.

R* activation Model: This model replaces the RecRK Ca⁺⁺ feedback with a feedback that modulates the effective catalytic gain of R* without altering its dynamics. This corresponds to an implementation of a scheme proposed by Lagnado & Baylor [2] to explain their observations that during the period of light exposure, experimental reduction of Ca⁺⁺ causes a substantial decrease in transduction gain, but no apparent change in response kinetics. Their results imply an early gain mechanism that acts as if it reduced the effective light intensity. The locus of action could be at the "activatability" of rhodopsin, or in the catalytic activity of R* in activating transducin and PDE. However, there is currently no known mechanism for this gain effect, and Lagnado & Baylor's results cannot distinguish between action at R* activation or transducin activation.

Hence, in the present implementation of the Lagnado & Baylor scheme, activation of R* is treated as Ca⁺⁺-sensitive, such that a reduction in internal Ca⁺⁺ reduces the number of R molecules activated by a flash. The Ca⁺⁺-effect is assumed to be rapid, and thus the feedback (denominator of the first term in Eq. 10) is written in the form of a Michaelis-Menten modulation of Φ, the number of R* generated by a brief flash. K_r in Eq. 10 is the K_1/2 for the Ca⁺⁺-effect on R* activation, with Hill coefficient n_r.

Here, 1/τ_R is the first-order rate-constant for inactivation of R*, replacing the pseudo-first order rate-constant, q₅RK*, of Eqs. 1 and 2. The rest of the Eqs. in this model are as in Eqs. 3 through 7. Again, two cases are examined (τ_E, and τ_R rate-limiting).

RecRK-R* activation Model: This model contains both of the additional (non-cyclase) feedback mechanisms: modulation of R* inactivation rate (q₅RK*, Eq. 12) and Ca⁺⁺-modulation of R* activation (denominator of the first term in Eq. 12). Both of these feedback reactions are embodied in Eq. 12.

All other Eqs. in this model are the same as in the RecRK model (i.e., Eqs. 2 through 9).

Four cases are examined for the RecRK-R* activation model. For each of the rate-limiting cases (τ_E and τ_R rate-limiting), the analysis is carried out twice, first under the assumption that the RecRK mechanism (modulation of R* lifetime) dominates the early gain control, and then under the assumption that the R* activation mechanism (modulation of R* activation gain) dominates the early gain.

Empirical Response Suite I

After optimization to the Murnick & Lamb saturated two-flash data and the sub-saturated flash responses, the models described above were used to "predict" the responses to a suite of DA and LA stimulus conditions obtained in other studies. These are shown in Figure 1 and Figure 2.

Figure 1A shows sub-saturated flash responses obtained from toad rods by Rieke & Baylor [16]. Each model was simultaneously optimized to a subset of these data (responses to the lowest four flash intensities) and to the Murnick & Lamb saturated data (shown in Figure 3).

Figure 1B shows step responses obtained from newt rods by Forti et al. [17]. These data have two qualitative, signature features that have been observed in similar recordings from rods of other species (e.g., salamander [22]; primate [18]). (1) A "nose" on the leading edge of the response that recovers slowly to a steady-state level. The relaxation to a steady-state presumably reflects the action of feedback gain mechanisms. (2) A pronounced, multi-phasic response at step-offset, exhibiting a fast recovery phase followed by a slow phase, with some damped resonant behavior in between. The slow phase may reflect a slow back-reaction from inactivated to activated rhodopsin [12,17].

Figure 1C shows a summary of the intensity-dependence of saturation period (T_sat) observed by Murnick & Lamb. The signature feature is the slope of the T_sat versus ln(I) function. The thick red dashed line in Figure 1C has a slope of 2.8 s/ln unit, the slope for the cell presented in Figure 3 of Murnick & Lamb. The cell presented in their Figure 3 (whose data are analyzed in this paper) only provided two data points on the T_sat function (filled red squares). However, the T_sat slope for this cell closely matches data from another rod presented in their Figure 1 (filled red circles), and is close to the average of the T_sat slopes of seven cells presented in their Table 1 (2.7 s/ln unit). Typically, the slope of T_sat versus ln(I) observed in amphibian rods is 2-3 s [1,12-14].

Figure 1D shows the decrease in flash sensitivity as a function of background light intensity (LA flash sensitivity). The data are from 6 newt rods studied by Torre et al. [23]. A number of studies have shown that the gain, as measured by the peak amplitude in response to a flash on a background, decreases according to the Weber-Fechner relation over several log units in rods [18,23-25], and over a larger range in cones [26]. The dashed red curve is the Weber-Fechner relation fit to the Torre et al. data [23]. The intensity that caused the incremental flash sensitivity to decrease by a factor of two (I_1/2) was 100 R*s^-1. The signature feature of note is the relatively large dynamic range over which flash sensitivity obeys the Weber-Fechner relation. In this case, the Torre et al. [23] data obeys the Weber-Fechner relation over a ~4 log unit intensity range.

Empirical Response Suite II

Figure 2 shows two additional elements of the Empirical Response Suite. The left panel reproduces the results of a step-flash paradigm used by Fain et al. (salamander rods; [27]). A saturating flash was applied after presentation of a 7 s conditioning step of light of increasing intensity (curves labeled 1, 2, 3). The flash response in the absence of a conditioning step is shown by the curve labeled DA. The signature feature to note is that the period of saturation (T_sat) in response to the flash decreases as the intensity of the conditioning step increases.

The right panel in Figure 2B shows the results of a Ca⁺⁺ clamp experiment by Matthews [2]. Tiger salamander rods were exposed to a 0 Ca⁺⁺/0 Na⁺ test solution for brief periods around the time of presentation of a super-saturating, 20 ms flash. The test solution minimizes simultaneously the influx and efflux of Ca⁺⁺, thus opposing the light-induced fall in Ca⁺⁺ [22,27-29]. Removal of external Ca⁺⁺ minimizes the influx of Ca⁺⁺ through the outer segment cation channels, while removal of external Na⁺ prevents Ca⁺⁺-efflux through the Na⁺: Ca⁺⁺,K⁺ exchanger.

Matthews applied the Ca⁺⁺ clamp at four time periods around the time of flash presentation (t=0): the test solution was applied either from 1 s before to 1 s after the flash ("Pre & Post" condition), or from the time of the flash until 1 s after the flash ("Post"), or from 1 s before the flash until the time of the flash ("Pre"), or from 1 s after the flash until 2 s after the flash ("Late"). The signature feature is that the Ca⁺⁺ clamp significantly prolonged the period of saturation only when the Ca⁺⁺ clamp was applied within a brief time window around the time of the flash ("Pre & Post" and "Post"), but not if it was applied too early ("Pre") or too late ("Late").

The prolongation was interpreted as reflecting a gain increase (relative to the gain with Ringer's solution) at a Ca⁺⁺-sensitive step early in the phototransduction cascade. By parametric variation of the timing of the application of the Ca⁺⁺ clamp solution and return to Ringer's solution, Matthews was able to map out a time course for the Ca⁺⁺-sensitivity of the gain effect (roughly exponential, with a time constant of ~0.5 s). Matthews proposed that the observed time constant of the Ca⁺⁺-effect might correspond to RecRK modulation of phosphorylation of R*.

Results

RecRK Model: τ_E Rate-Limiting

The Murnick & Lamb data can be accounted for with PDE* lifetime rate-limiting.

With τ_E rate-limiting, the RecRK model provides an excellent account of the Murnick & Lamb data. The panels in Figure 3A show the Murnick & Lamb saturated two-flash data (in red) and the model fits (in blue) for delays of 0, 1, 2, 3 s (left column of panels), and 4, 6, 8, and 10 s (right column of panels). The parameters for the model are given in Table 2, and a description of the variables and parameters for all models is given in Table 1.

In each panel of Figure 3A, the time at which the Test flash was presented is indicated by an inverted green triangle near the abscissa (as this triangle moves to the right on the abscissa, the delay between Pre- and Test flashes increases); the red star near the top of each panel marks the time at which the response to the Test flash would have emerged from saturation if the Pre-flash had not affected Test flash saturation period. Note that the data remain in saturation for progressively less time as delay increases (i.e., the time between the saturated data and the red star increases as delay increases).

The plot of Test flash T_sat versus delay (derived from Figure 3A) is shown in Figure 3B. The model responses are shown as blue filled circles and solid blue curves, and the Murnick & Lamb data are shown as red filled squares with a red solid curve. The dashed lines have a slope of -1, and are placed to pass through the first data point (at delay = 0) for both the model results and the data. The data fall below this line out to a delay of 6-7 s, illustrating the signature feature that the change in T_sat can exceed the delay. The model results capture this feature, and also fall below the corresponding blue line of slope -1.

In addition, after optimization to the Murnick & Lamb data and the sub-saturating flash responses, the RecRK model (with τ_E rate-limiting), using the same set of optimized parameters, reproduces all the salient qualitative features of the DA and LA responses in the Empirical Response Suites shown in Figure 1 and Figure 2. The fits to the sub-saturated toad rod flash responses are shown in Figure 4A. The model is able to provide a reasonable account of the four sub-saturating responses to which it was optimized (four smallest responses in Figure 4A) as well as to responses to five higher intensities (to which the model was not optimized). Figure 4B shows the model step responses, which exhibit the two qualitative features seen in the newt rod responses of Figure 1B, namely the "nose" at step onset and the two-phase response at step offset. The slow phase of the step-offset response is due to the back-reaction between R and R* in the model [17,23]. Figure 4C shows the model T_sat versus ln(I) function (blue solid curve) along with the empirical T_sat data from Murnick & Lamb (dashed red line and red data). The model T_sat versus ln(I) function reproduces the same slope (~2.8 s/ln unit) as the Murnick & Lamb data. This slope is set by the rate-limiting τ_E (Table 2).

The model also generates a substantial range of Weber's law LA flash sensitivity (~3 log units; solid blue curve, Figure 4D). For each of a series of background adaptation levels (I_b), model LA flash sensitivity was defined as the amplitude of the response to a flash of fixed criterion intensity divided by the intensity of the criterion flash. The criterion was the flash intensity eliciting a DA flash response amplitude that was 10% of the full range of circulating current. The dashed red curve is the Weber-Fechner relation from Figure 1D, shifted horizontally to fit the model output below a "cutoff" background intensity (cutoff I_b), above which the model was judged to deviate from Weber's law. The cutoff I_b is marked by the black dashed vertical cursor in Figure 4D, and its definition is given in the legend to Figure 4.

The model LA flash sensitivity obeys Weber's law over a significant range (cutoff I_b = 8000 R* s^-1). At the cutoff I_b, 14% of the model DA circulating current (F_ss) remains, as indicated by the intersection of the vertical cursor line with the green solid curve. The latter plots the fraction that the steady-state current is saturated (i.e., 1 - F_ss(I_b)), where F_ss is the steady-state circulating current defined to be 1.0 in the dark, and zero when all channels are closed. Also, at the cutoff I_b, the steady-state internal Ca⁺⁺ level (c_ss in inset) has dropped by a factor of 5.1, from a dark value of 0.3 μM to 0.059 μM.

Also shown is the LA flash sensitivity of the model under two types of simulated Ca⁺⁺ clamp conditions: (1) LA flash sensitivity with Ca⁺⁺ clamped at its dark value (Ca_dark⁺⁺ clamp; blue dash-dot curve). Ca⁺⁺ -feedback is fully disabled over the entire dynamic range, with only static saturation contributing to flash desensitization. Ca⁺⁺ was fixed at its dark value in the model, and I_b was adjusted to achieve the same steady-state current as in the unclamped case, ensuring that the steady-state currents were at the same level in relation to static saturation (i.e., cGMP-gated channel). Differences in flash sensitivity then can be ascribed to the differing states of Ca⁺⁺ in the unclamped and clamped cases.

The Ca_dark⁺⁺ clamp analysis equates steady-state current levels (F_ss), but does not equate internal Ca⁺⁺ levels at the time of presentation of the flash. This is achieved in a second analysis: (2) LA flash sensitivity with Ca⁺⁺ clamped at the new steady-state level reached in response to each I_b (Ca_ss⁺⁺ clamp; blue dashed curve). This approach equates the F_ss (and hence equates the effect of channel saturation), and equates Ca⁺⁺ at the time of the flash. Thus, in comparing the unclamped and the Ca_ss⁺⁺-clamped flash sensitivity, the LA flash response in each case is affected equally by saturation and by the steady-state level of Ca⁺⁺-mediated gain. The only additional factor shaping the LA flash response in the unclamped case is the dynamic Ca⁺⁺-mediated gain change evoked by the flash.

Note that at high I_b (I_b> cutoff I_b), the unclamped model flash sensitivity falls more steeply than a Weber's law slope of -1, and eventually follows a steep function that parallels the high - I_b behavior of both Ca⁺⁺ clamped curves. In fact, all 3 curves asymptote to a slope of -(n_cg + 1), which is predicted by the instantaneous compressive saturation of the cGMP-gated channels [30].

The analyses in Figure 4D (which are recapitulated in all subsequent similar figures) aid in seeing the magnitude of the Ca⁺⁺-mediated adaptational gain control and the intensity range over which it is exerted. They also help dissect the model sensitivity losses due to dynamic gain mechanisms from those due to static (channel) saturation of the model. For example, the Ca_dark⁺⁺ clamp analysis (blue dash-dot curve) shows vividly how much the two Ca⁺⁺ feedback mechanisms protect the rod from rapidly losing sensitivity (as I_b increases) due to the static saturation of the cGMP-gated channel. Moreover, both Ca⁺⁺ clamp analyses show that, although the dynamic Ca⁺⁺-mediated gain mechanisms lead to some absolute loss of sensitivity (especially at low I_b), the rate of decrease of sensitivity with I_b is greatly diminished by the gain mechanisms, permitting Weberian desensitization over a large dynamic range. Finally, it can be seen from the analyses that a significant amount of cGMP-gated membrane channels remain open even at the cutoff I_b where the model begins to fall off more sharply than Weber's law (F_ss at the cutoff I_b is 0.14, and is close to this value in all subsequent similar figures).

With the same parameters, the RecRK model with τ_E rate-limiting also reproduces the signature features of the Fain et al. [27] data; the model saturated flash response emerges out of saturation faster as the intensity of a conditioning step is increased (Figure 5A). Under simulated Ca⁺⁺ clamp, the model also reproduces the qualitative behavior of the Matthews [3] data (Figure 5B); the period of saturation (blue solid curve) is prolonged (blue dashed curve) by the application of the Ca⁺⁺ clamp near the time of the flash ("Pre & Post", "Post"), but not if the flash occurs too early ("Pre") or too late ("Late").

RecRK Model: τ_R Rate-Limiting

The rate-limiting step cannot also be the Ca⁺⁺-sensitive step in a RecRK model.

The analyses show that R* lifetime cannot be rate-limiting in a model in which RecRK is the only early gain mechanism. In simulating the data with the RecRK model, the salient features of the Murnick & Lamb data can only be accounted for if PDE* lifetime, and not R* lifetime is rate-limiting [1]. One critical failure of the model is that, with τ_R rate-limiting, model Testflash T_sat cannot exceed the magnitude of the delay between Pre- and Test flashes. This is illustrated in Figure 6, which shows Test flash T_sat versus delay for the model (blue) and the Murnick & Lamb data (red). The model results are always above the dashed blue line with slope -1, depicting the fact that the change in model T_sat never equals or exceeds the magnitude of the delay. This failure rules out a model structure in which R* lifetime is rate-limiting and in which early Ca⁺⁺ feedback occurs solely at R* lifetime (via RecRK; [1]).

Rate-limitation by R* lifetime in a RecRK model is incommensurate with the kinetics of the dim-flash response.

Other fundamental constraints mitigate against R* lifetime being rate-limiting in a model with RecRK as the only early gain mechanism. In order to achieve the gain change observed by Murnick & Lamb (10-15x), the time constant of R* inactivation must decrease by 10-15 times from its dark level to its minimum (τ_Rmin) as Ca⁺⁺ approaches its physiological minimum (c_min, Eq. 4). Empirical data from measurement of the intensity dependence of T_sat (T_sat versus ln(I); [1,12-14,20]) place bounds on the value of the rate-limiting recovery time constant, i.e., ~2-3 s. This means that when Ca⁺⁺ approaches c_min, τ_R can fall to no less than 2-3 s to remain the rate-limiting reaction with a time constant commensurate with empirical measures of T_sat. Thus, the dark values of τ_R (τ_Rdark) must be greater than or equal to 20-30 s, forcing the dim-flash flash response to be anomalously prolonged. This problem is illustrated in Figure 7. The top panel shows the relationship between τ_R and the level of Ca⁺⁺ as it falls from a dark value of 0.3 μM to a minimum of 0.02 μM. Over this range of Ca⁺⁺, τ_R falls from 20 s to ~2 s. The bottom panel of Figure 7 shows the resulting dim-flash response (blue curve) in comparison to an empirical response (red). The model response was the result of optimizing the RecRK model to the Murnick & Lamb data and to the sub-saturating flash responses with the RecRK parameters set to generate the profile in the top panel of Figure 7. The resulting model dim-flash response can capture much of the early response of the cell due to the influence of Ca⁺⁺ feedback on recovery, but it has a very prolonged recovery "shelf" reflecting the 20 s (DA) rhodopsin inactivation time constant. This prolonged response profile is not seen in normal, healthy rod responses.

RecRK Model: General Considerations

The need for a large front-end Ca⁺⁺-mediated gain severely constrains RecRK parameters.

If the full gain modulation underlying the Murnick & Lamb data (~10-15x) is assumed to be generated via modulation of τ_R, this puts strong constraints on some of the biochemical parameters of the RecRK reactions. This is true regardless of which is the rate-limiting reaction, R* or PDE* lifetime.

The model can help to illustrate this problem. Figure 8 shows how the maximum effective "front-end" gain change depends on some of the key biochemical parameters governing the interaction between Rec and Ca⁺⁺, and between Rec* and RK (here Rec* symbolizes Rec bound to wCa⁺⁺ ions, the species that inhibits RK).

The ordinate in Figure 8 is the maximum, steady-state change in effective R* Gain, defined as the calculated steady-state change in R* lifetime when Ca⁺⁺ falls from its dark level (0.3 μM in this example; [31]) to its physiological minimum (0.02 μM in this example [32-34]; ΔGain = τ_R,dark/τ_{R,Ca_min}). It can be seen from Eq. 1 that any process that increases RK* effectively increases the rate of inactivation of R* (decreases R* lifetime, τ_R). From Eq. 8 it can be seen that the steady-state level of RK* will be set by the ratio of q₄ to q₃, the dissociation constant (K_D = q₄/q₃) for the interaction between RK and Rec* (see Appendix 1, Eqs. A13 and A14). Hence K_D is plotted on the abscissa of Figure 8.

The level of RK* is also determined by the parameters governing the interaction of Rec and Ca⁺⁺. For a given Ca⁺⁺ level, the amount by which RK* can change depends on the affinity of Rec for Ca⁺⁺ and the resultant amount of Rec* available. Hence, the different curves in Figure 8 show the Gain versus K_D for different values of K_Rec,Ca. The latter parameter is the K_1/2 for the interaction between Ca⁺⁺ and Rec, i.e., the Ca⁺⁺ concentration at which 1/2 of the Rec is bound to Ca⁺⁺ (the state in which it inhibits RK, thus slowing R* inactivation). The curves shown correspond to candidate K_Rec,Ca values ranging from 0.2 to 1.2 μM (from top to bottom, in 0.1 μM increments). The red curve corresponds to a biochemical estimate for this parameter (K_Rec,Ca=0.9 μM) obtained by Klenchin et al. [8]. The horizontal dashed line occurs at a gain change of 10.

The curves in Figure 8 illustrate that K_D must be very small if other RecRK and Ca⁺⁺ parameters are set to values estimated in the literature. For a value of K_Rec,Ca = 0.9 μM (the in vivo estimate by Klenchin et al. [8]), K_D must be less than ~0.25 μM in order to achieve a gain change of 10x or more (the gain change implied by the large decreases in T_sat in the Murnick & Lamb data). This value for K_D is ~14 times less than the value estimated by Klenchin et al. (~3.4 μM; [8]) in an in vitro study with bovine tissue. K_D will be even more severely constrained (to even smaller values) if it is assumed that the minimum physiological value for Ca⁺⁺ is greater than 0.02 μM.

Note that each of the curves is quite steep in the region of high gain values (10x or more). This means that, not only is K_D restricted to small values, but the overall range of (small) K_D values that are permissible in order to achieve the empirically observed gain changes is highly restricted.

If we knew a priori that the RecRK feedback only generated gain changes on the order of 2-4x, a significantly broader range of values for K_D would be permissible. However, in this case, to achieve the an overall gain change of 10x or more, there would need to be an additional feedback mechanism(s) contributing to the overall large gain change, such as a gain affecting R* catalytic activity [2]. Two models that include this kind of gain mechanism are examined in the following sections.

R* activation Model: General Considerations

An R* activation model accounts for the Murnick & Lamb data regardless of what is the rate-limiting reaction

τ_E Rate-Limiting: A model containing Ca⁺⁺-modulation of R* activation as the sole early gain mechanism (Eqs. 3-7, 10,11) can account for the Murnick & Lamb data regardless of whether τ_R or τ_E is rate-limiting. Figure 9 shows the results for τ_E rate-limiting. The left panels (Figure 9A) show the excellent fit of the model to the Murnick & Lamb saturated two-flash data. The right panel (Figure 9B) shows the corresponding model Testflash T_sat versus delay along with the Murnick & Lamb data. As was seen in comparable results from the RecRK model (Figure 3B), the model is able to capture the critical feature of the data, i.e., that the decrease model Test flash T_sat in response to the Pre-flash can exceed the delay (blue curve falls below dashed blue line with slope = -1).

Figure 10A shows the model fit to the sub-saturating flash responses, while Figure 10B-D shows the model step responses, T_sat versus ln(I), and LA flash sensitivity, respectively. Clearly the model was able to achieve a reasonable fit to the Murnick & Lamb data, while providing a good account of the sub-saturating flash responses. In addition, the model captures the salient features of the other DA and LA responses, including a relatively large range of LA flash sensitivity adhering to Weber's law (Figure 10B-D).

τ_R Rate-Limiting: When τ_R is rate-limiting, the R* activation model can achieve a good fit to the Murnick & Lamb data (Figure 11), as well as to the sub-saturated flash responses (Figure 12A).

These results alone demonstrate that the Murnick & Lamb results can be accounted for by a model in which the rate-limiting step early in the cascade is also Ca⁺⁺-sensitive, as long as Ca⁺⁺ does not act on the recovery time constant of the target reaction.

With the same parameters, the R* activation model (with τ_R rate-limiting) also reproduces the salient features of amphibian rod step responses (Figure 12B), the empirical T_sat versus ln(I) function (Figure 12C), as well as a large dynamic range of Weber's law LA flash sensitivity (Figure 12D). In addition, it reproduces the qualitative behavior observed by Fain et al. [27] in their step-flash paradigm, regardless of whether τ_E (top panel of Figure 13A) or τ_R (bottom panel Figure 13A) is rate-limiting.

A pure R* activation model can be ruled out

Despite its ability to account for the Murnick & Lamb data and other representative response profiles, the R* activation model can, nevertheless, be ruled out because it fails to predict the Matthews [3] Ca⁺⁺ clamp data. This is shown in the right panels of Figure 13B. The top pair and bottom pair of panels are for τ_E and τ_R rate-limiting cases, respectively. Note that in both cases, the model does not predict a significant extension of saturation period under Ca⁺⁺ clamp conditions. This failure implies that the R* activation model, and any similar model (with an early Ca⁺⁺ feedback up to and including PDE activation) that does not alter the recovery kinetics of the target reaction, can be ruled out.

RecRK-R* activation Model: Dominance by Gain at R* activation

The RecRK-R* activation model combines both early feedbacks, i.e., at R* activation and at R* lifetime (Eq. 12). As was seen with the R* activation model, the analyses show that the Murnick & Lamb data can be accounted for when τ_R is both rate-limiting and Ca⁺⁺-sensitive if, in addition to the RecRK feedback, there is an earlier, stronger Ca⁺⁺ feedback (i.e., Ca⁺⁺ feedback at R* activation) that does not affect R* inactivation kinetics. This is shown in Figure 14, Figure 15, and Figure 16.

τ_R is rate-limiting: Figure 14 shows results for the case where τ_R is rate-limiting. Since the results for τ_E rate-limiting were virtually the same, and since rate-limitation by τ_R is the more challenging of the two cases (i.e., when τ_R was rate-limiting, the RecRK model failed to capture the Murnick & Lamb data; Figure 6), only the results for τ_R rate-limiting case will be shown.

The model provides a good overall fit to the Murnick & Lamb data (Figure 14A). Moreover, the corresponding plot of Testflash T_sat versus delay (Figure 14B) shows that, in contrast to the RecRK model (Figure 6), with τ_R rate-limiting, the model can generate a decrease in Testflash T_sat that exceeds the magnitude of the delay (model results fall below the blue dashed line with slope -1).

In addition, the model fits the sub-saturated flash responses (Figure 15A), and accounts for the signature qualitative features of step responses (Figure 15B) and T_sat versus ln(I) (Figure 15C). The model also generates a relatively large dynamic range of LA flash sensitivity adhering to the Weber-Fechner relation (Figure 15D). Finally, the model captures the qualitative features of both the step-flash data of Fain et al. [27] (Figure 16A), and the Ca⁺⁺ clamp data of Matthews [3] (Figure 16B).

RecRK-R* activation Model: Dominance by Gain at R* lifetime

In contrast to the case where R* activation gain is dominant, if Ca⁺⁺-modulation of R* lifetime is the dominant of the two early gain mechanisms in the combined model, the large decreases in Testflash T_sat observed by Murnick & Lamb cannot be reproduced (as was seen in the analyses of the RecRK model; Figure 6). This is shown in Figure 17 (Testflash T_sat versus delay). Unlike the data (red), the model never falls below the dashed blue line with slope -1 because the change in Testflash T_sat never exceeds the delay (compare with Figure 3B and Figure 14B). Thus, if both R* activation and R* lifetime (RecRK) gains are present, the R* lifetime gain cannot dominate.

Discussion

The overall goal of the present study was to evaluate model structure(s) that might be commensurate with both the highly nonlinear data of Murnick & Lamb and a suite of representative DA and LA rod data. A standard model of phototransduction, with only one Ca⁺⁺ feedback locus at a late stage in the cascade (i.e., cGMP-synthesis), cannot generate the primary observations of Murnick & Lamb's two-flash data [1] or the Fain et al. step-flash data [27]; no combination of parameters will permit such a model to predict a reduction in Testflash saturation period as a result of prior stimulation, nor can such a model account for the Matthews [3] Ca⁺⁺ clamp data.

In order to account for the striking experimental observations of Murnick & Lamb [1], as well as those of Fain et al. [27] and Matthews [3], at least one additional feedback mechanism is required. Three candidate models were implemented and evaluated: feedback at R* lifetime (RecRK model), feedback at R* activation with no change in R* inactivation kinetics (R* activation model), and a combined model with both early feedbacks (RecRK-R* activation model).

RecRK Model

τ_R cannot be rate-limiting if it is the only early, Ca⁺⁺-sensitive gain mechanism

Analysis of the RecRK model confirmed Murnick & Lamb's [1] prediction that when R* lifetime is Ca⁺⁺-sensitive, PDE* lifetime must be rate-limiting in order to account for all the features of their data (Figure 4, Figure 5, and Figure 6). Ca⁺⁺-regulation of a rate-limiting τ_R fails to capture at least one crucial feature of the Murnick & Lamb data: the large change in T_sat that can exceed the magnitude of the delay between Pre- and Test flashes. This failure rules out a model in which Ca⁺⁺-mediated modulation of a rate-limiting τ_R is the single early gain mechanism.

With PDE* lifetime rate-limiting (i.e., the dominant early recovery reaction), the effective time constant of the non-dominant recovery reaction (i.e., τ_R) would be constrained to be less than ~1 s in the dark, and would have to decrease by 10-15x as Ca⁺⁺ level dropped to its physiological minimum. Estimates of the non-dominant recovery time constant with Ca⁺⁺ clamped at its dark level have been reported to be 0.4-0.5 s for amphibian rods [19,20]. This means that τ_R would have to fall to quite small values (40 to 50 ms) during photocurrent saturation in order to effect the requisite gain change.

The analyses also showed that rate-limitation by R* lifetime in a RecRK model imposes other serious constraints. With τ_R rate-limiting, the change in τ_R required to reproduce both the observed gain changes (10-15x) and the empirical intensity-dependence of T_sat (2-3 s/ln unit [1,12,14,22]) is incommensurate with the dynamics of dim-flash responses (Figure 7). In order to be compatible with both empirical T_sat data and the Murnick & Lamb data, τ_R would have to transition between 20-30 s in the dark to 2-3 s in complete photocurrent saturation (when Ca⁺⁺ approaches c_min), thus yielding an inordinately prolonged dim-flash response (Figure 7).

Finally, the analysis of the RecRK model showed that it is difficult to account for the full gain change (~10-15x) implied by the Murnick & Lamb data by modulation of R* lifetime using parameters in the range of current empirical estimates (Figure 8). This is true regardless of which is the rate-limiting recovery reaction (PDE*- or R* lifetime).

R* activation Model

In principle, τ_R can be rate-limiting and Ca⁺⁺-sensitive if the gain occurs at R* activation.

The limitations of the RecRK model led us to examine an alternative scheme suggested by Lagnado & Baylor [2] (R* activation model; described in Methods, Models). The results showed that when the Ca⁺⁺-dependent gain change occurs at the locus of effective R* catalytic gain, all the key features of the Murnick & Lamb data can be captured regardless of whether τ_E or τ_R is the rate-limiting recovery time constant (Figure 8, Figure 9, Figure 10, and Figure 11). Moreover, the model provides a reasonable account of several of the responses included in the Empirical Response Suites. These results demonstrate that, in principle, the Murnick & Lamb results can be explained by a model in which Ca⁺⁺ feedback modulates effective R* catalytic gain as long as the gain change does not alter R* inactivation kinetics. This same conclusion applies to any reaction prior to PDE activation, as long as the gain change does not alter the inactivation kinetics of the target reaction.

The R* activation model can be rejected

Despite the success at capturing the Murnick & Lamb data as well as many of the salient features represented in the Empirical Response Suites (Figure 9,Figure 10,Figure 11,Figure 12, and Figure 13A), the R* activation model is unable to simulate one key data set, i.e. the extension of saturation period observed by Matthews [3] when changes in internal Ca⁺⁺ are minimized for a brief period around the time of the saturating flash (Figure 13B). This failure rules out this specific model, and a whole class of models in which the feedback action of a Ca⁺⁺-decrease is to decrease the gain of any stage up to and including PDE* activation without changing the effective dynamics of the target reaction's inactivation.

Pugh et al. [35] also provide evidence that an R* activation model can be rejected. If Ca⁺⁺ feedback significantly decreased R* catalytic gain, Pugh et al. reason that it would cause a decrease in the slope of the early rising phase of LA flash responses. However, they present evidence that the early rising phase of the photocurrent of LA flash responses follows an invariant trajectory independent of background intensity. However, several other studies have found evidence that the early rising phase of the LA flash response is not invariant with intensity [10,11,36,37].

If, indeed, the rising phase is invariant with background intensity, this argues against the existence of any decrease in R* catalytic gain, and thus argues against two of the three models analyzed in the present study (either the pure R* activation model or the combined RecRK-R* activation model). However, as discussed in the section above, the remaining model (RecRK) has serious limitations in accounting for all the data using available estimates for key biochemical parameters. This suggests the need to implement other feedback mechanisms. Ca⁺⁺ feedback onto the affinity or Hill coefficient of the channel for cGMP [38-41] have not been implemented in the present study, but these mechanisms cannot generate the Murnick & Lamb results. Hence, other, as yet unknown mechanisms that can affect early transduction gain may be needed.

Combined RecRK-R* activation Model

A Ca⁺⁺-sensitive τ_R can be rate-limiting if gain at R* activation is dominant

When both early Ca⁺⁺ feedbacks are included (RecRK-R* activation model), the model can account for the Murnick & Lamb data as well as many of the features of the empirical suite of responses regardless of whether τ_E or τ_R is rate-limiting, as long as Ca⁺⁺-modulation of R* activation is the dominant of the two gain mechanisms (Figure 14, Figure 15, and Figure 16). If the gain at τ_R is dominant, as was seen for the RecRK model (Figure 6), the large decreases in Testflash T_sat observed by Murnick & Lamb cannot be reproduced, thus eliminating this as a viable scheme (Figure 17).

General Considerations

Is PDE* lifetime or R* lifetime rate-limiting?

Overall, the models are able to capture a broader range of DA and LA features with parameters in the range of empirical estimates when PDE*-inactivation is the rate-limiting reaction. However, the analyses of the R* activation and RecRK-R* activation models showed that, in principle, the Murnick & Lamb data alone are not sufficient to unequivocally identify the rate-limiting reaction in the early cGMP cascade. The present analyses demonstrated that the Murnick & Lamb data can be accounted for by a model in which R* lifetime is both rate-limiting and Ca⁺⁺-sensitive if, in addition to feedback via RecRK, an early, stronger feedback is present. The stronger feedback must be such that it does not significantly alter the recovery kinetics of the rate-limiting reaction. Hence, the question of whether τ_R [12-14] or τ_E [1,3,19,20,42] is the rate-limiting recovery time constant still remains open.

Role of some key biochemical parameters

In a recent article, Hamer [15] showed that two models (one based on the Nikonov et al. [20] model which used an instantaneous Ca⁺⁺-buffer, and one with a dynamic Ca⁺⁺-buffer) failed to be able to capture a suite of rod responses when some key biochemical parameters were held near their current best empirical estimates. One key failure resulted when n_Ca (the Hill coefficient for Ca⁺⁺ feedback onto guanylate cyclase) was held to ~2.2 [43-46]. In this case, the models were able to generate LA flash sensitivity adhering to Weber's law over only a small intensity range. Only when n_Ca was large (i.e., approaching 4) could the models generate a large dynamic range of Weberian LA similar to that observed by Forti et al. [17].

This result (and other failures using "modern" parameters values) implied that the models analyzed in Hamer [15] lacked one or more important mechanisms. In particular, the failure to reproduce empirical LA behavior using "modern" cyclase Ca⁺⁺ feedback parameters suggested the possibility that with additional Ca⁺⁺ feedback, a model might be able to reproduce the empirical LA behavior with n_Ca held at or near its modern empirical estimate (~2.2).

The present work has analyzed models with additional feedback mechanisms in place. One finding (not described in the Results) was that with Ca⁺⁺ feedback at R* lifetime in place (RecRK model), the model was able to fit the Murnick & Lamb [1] data (Figure 3), the sub-saturated flash responses (Figure 4A), and all the other key qualitative features of the Empirical Response Suites (Figure 4B,C and Figure 5), including generation of a large range of LA flash sensitivity adhering to Weber's law (Figure 4D) using a value of n_Ca = 2.5 instead of ~4 [15] (see Table 2). Moreover, these results were achieved with 10 other key biochemical parameters set to within ± ~60% (0.2 log units) of their modern empirical estimates (Table 2): Rec_tot = 35 μM (empirical estimate = 34 μM [8]); RK_tot = 7 μM (~1/5 Rec_tot [8]); K_Rec,Ca = 0.53 μM (0.87 μM [8]); w = 2.5 (empirical estimate = 2 [8]); β_dark = 0.5 s^-1 (empirical estimate = 0.5 - 1 s^-1 [16,20,47,48], reviewed in [15]); K_Ca = 0.14 μM (empirical estimate = 0.1 to 0.2 μM [43-45,49,50], reviewed in [15] and [51]); n_cg = 2.59 (empirical estimate = 1.6-3 [24,52-56]); f_Ca = 0.3 (empirical estimate = 0.10 - 0.25 [17,22,28,57,58] Korenbrot, personal communication); c_dark = 0.3 μM (0.2 - 0.7 μM [31,34,59-62]); c_min = 0.02 μM (empirical estimate = ~0 - 0.05 μM [33,34,63-65]).

Some implications for vertebrate photoreceptor light adaptation

Weber's law and the value of n_Ca: This paper has evaluated models having one or two Ca⁺⁺ feedback mechanisms in addition to the more well-studied feedback onto cGMP-synthesis (via Ca⁺⁺-mediated stimulation of guanylate cyclase). Each model was able to generate a relatively large range of LA flash sensitivity adhering to Weber's law (see Figure 4D, Figure 10D, Figure 12D, and Figure 15D). These results are in contrast to the results of an earlier analysis which found that the Nikonov et al. model [20] was not able to generate a large range of Weberian LA and, with the same set of parameters, capture the features of other DA and LA responses [15]. Moreover, with the Hill coefficient for the cooperative interaction between Ca⁺⁺ and cyclase held to its modern empirical estimate ~2 (n_Ca = ~2; [43-45]), the Nikonov et al. model [20] generates only a modest range of Weber's law LA flash sensitivity.

Addition of a dynamic Ca⁺⁺-buffer to the Nikonov et al. model [20] conferred the ability to capture a number of signature empirical features and generate a significantly larger range of Weber's law LA flash sensitivity [15]. However, the model had only the one Ca⁺⁺ -feedback (onto cyclase), and the extended range of LA behavior could only be obtained when the Hill coefficient for cooperative action of Ca⁺⁺ onto cyclase activity (n_Ca) was high (~4).

The present results show that, with additional Ca⁺⁺ feedback, a large range of Weber's law LA flash sensitivity can be generated with a relatively low cyclase Hill coefficient. For example, the combined RecRK-R* activation model (Figure 14, Figure 15, and Figure 16) captures the Murnick & Lamb data as well as the array of signature features of the suite of DA and LA empirical responses with a value of 2.38 for n_Ca, close to the modern estimates [43-45].

Effects of steady increases in Ca⁺⁺ feedback on flash sensitivity

Pugh et al. [35] point out that a steady increase in Ca⁺⁺ feedback (due to a steady I_b) extends the photoreceptor's operating range by "protecting" the cell from sensitivity losses due to the instantaneous saturation imposed by the cGMP-gated channels. In addition, they claim that steady increases in Ca⁺⁺ feedback will either increase or decrease LA flash sensitivity depending on the specific locus of the feedback.

For example, Pugh et al. [35] claim that a steady increase in cyclase activity will increase flash sensitivity. The analyses of flash sensitivity presented in Hamer [15] argue against this being a general rule. In that paper, in which the models had only one feedback at guanylate cyclase, the Ca_dark⁺⁺-clamped sensitivity was higher than the unclamped sensitivity at low to moderate I_b, and lower than the unclamped sensitivity at high I_b. This means that the effect of steady increases in cyclase activity was to decrease flash sensitivity over low to moderate I_b, and to increase flash sensitivity at high I_b. In fact, the relative increase in sensitivity conferred by the steady increase in cyclase activity could be ascribed, in large part, to the extended operating range. Without Ca⁺⁺ feedback, the Ca_dark⁺⁺-clamped sensitivity fell below the unclamped sensitivity due to static saturation of the channels, i.e., when the steady circulating current in the clamped condition began to approach saturation (<~20% circulating current remaining).

The same pattern can be seen in the present analyses (Figure 4D, Figure 10D, Figure 12D, and Figure 15D). However, in the present models, Ca⁺⁺ acts at one or more of two additional loci (RecRK or R* activation or both). Pugh et al. [35] point out that steady increases in feedback at these loci will have the effect of decreasing flash sensitivity. Hence, the lower sensitivity of the unclamped function at low/moderate I_b could be due to the effect of Ca⁺⁺ feedback at RecRK and/or R* activation. Nevertheless, the net combined effect on sensitivity of all the active Ca⁺⁺ feedbacks in the present models was to decrease sensitivity for all I_b causing less than or equal to ~15% reduction in (unclamped) circulating current, or ~75% reduction in current in the Ca_dark⁺⁺-clamped condition.

In order to check the relative contribution of RecRK and/or R* activation gain (versus feedback gain at cyclase), the models were run with the RecRK and/or R* activation feedbacks disabled, (using the same parameters as in Table 2, Table 3, and Table 4), leaving only the feedback at cyclase functional. The result was a small increase in flash sensitivity at low to moderate I_b (as expected). Under these conditions, the effect of a steady increase in cyclase activity was (as in Hamer [15]) to decrease flash sensitivity for all I_b causing less than or equal to ~70% reduction in current under Ca_dark⁺⁺ clamp. This result implies that the relatively lower sensitivity under unclamped conditions at low/moderate I_b was not due simply to a desensitization imposed by decreases in τ_R and/or R* activation gain. The desensitization must be due to the feedback at cyclase. A more direct demonstration of this was achieved by re-running the models while disabling Ca⁺⁺ feedback onto cyclase. This resulted in a virtual elimination of the difference between the unclamped and Ca_dark⁺⁺-clamped sensitivities at low/moderate I_b.

The above analyses show that steady-state increases in cyclase activity do not necessarily lead to an increase in LA flash sensitivity as claimed by Pugh et al. [35]. Light adapted flash sensitivity is more complex, with sensitivity depending on the net balance between dynamic sensitivity regulation mechanisms and static saturation influences,including pigment bleaching. It is also important to note that the balance between these is not necessarily a monotonic function of background intensity.

Effects of transient increases in Ca⁺⁺ feedback on flash sensitivity

Pugh et al. [35] claim that when Ca⁺⁺ is clamped at its new steady-state level set by each background, the resulting flash sensitivity function has approximately the same shape (intensity-dependence) as the unclamped function. The analyses in the present article and in Hamer [15] show that, strictly speaking, this is not the case. The shape of the Ca_ss⁺⁺ clamp (blue dashed curves in Figure 4D, Figure 10D, Figure 12D, and Figure 15D) is not the same as either the unclamped model responses (solid blue curves) or the theoretical Weber-Fechner relation (red dashed curves in same Figures); it falls off more quickly with intensity. The only difference between the Ca_ss⁺⁺-clamped and unclamped conditions is presence or absence of transient increases in Ca⁺⁺ feedback due to the flash. Hence, the model results serve to illustrate that the effect of these relatively small transient increases in Ca⁺⁺ feedback can be important for light adaptation, in that they tend to make the flash sensitivity fall off more slowly with background intensity.

Importance of modeling a broad range of data

The results of Murnick & Lamb are reminiscent of some earlier data by Fain et al. [27] reproduced in the present article (Figure 2). Although the reduction in saturation period observed by Fain et al. [27] may be explained by the same mechanism that reproduces the Murnick & Lamb results, the Fain et al. data did not have features that could be used to identify the rate-limiting and Ca⁺⁺-sensitive reactions within the context of a model of the form of the RecRK model.

The limitations of the Fain et al.data, as well as the results of the present analyses illustrate the importance of evaluating candidate models in relation to sets of data obtained under the broadest possible range of DA and LA conditions. A model may be able to generate an excellent quantitative fit to one or more sets of data (e.g., Figure 9, Figure 10, and Figure 12) and yet fail to capture even qualitative features of other representative responses (e.g., failure of the R* activation model to reproduce the Matthews data; Figure 13B). To the extent that the critical data are truly representative of the cell's response repertoire, such failures can rule out the candidate model.

Hence, the data to be simulated must be carefully chosen, with some attention to reliability. Moreover, analyses are aided by the presence of reproducible signature, qualitative features in the data since these tend to constrain the domain of acceptable model structures and/or parameter sets.

Acknowledgements

This work was supported by NEI Grant EY11513 and Smith-Kettlewell Eye Research Institute Grant 0100-10-52.

I would like to thank Juan I. Korenbrot, Ph.D. and Norberto M. Grzywacz, Ph.D. for their helpful comments about the physiological data and analyses. In addition, I am grateful for the skillful assistance of my programmer, Spero C. Nicholas, M.S. in carrying out the analyses, and technical assistance of Robert D. Flint, III, B.S.E.

References

1. Murnick JG, Lamb TD. Kinetics of desensitization induced by saturating flashes in toad and salamander rods. J Physiol 1996; 495:1-13.

2. Lagnado L, Baylor DA. Calcium controls light-triggered formation of catalytically active rhodopsin. Nature 1994; 367:273-7.

3. Matthews HR. Actions of Ca2+ on an early stage in phototransduction revealed by the dynamic fall in Ca2+ concentration during the bright flash response. J Gen Physiol 1997; 109:141-6.

4. Kawamura S, Murakami M. Calcium-dependent regulation of cyclic GMP phosphodiesterase by a protein from frog retinal rods. Nature 1991; 349:420-3.

5. Kawamura S. Rhodopsin phosphorylation as a mechanism of cyclic GMP phosphodiesterase regulation by S-modulin. Nature 1993; 362:855-7.

6. Kawamura S, Hisatomi O, Kayada S, Tokunaga F, Kuo CH. Recoverin has S-modulin activity in frog rods. J Biol Chem 1993; 268:14579-82.

7. Chen CK, Inglese J, Lefkowitz RJ, Hurley JB. Ca(2+)-dependent interaction of recoverin with rhodopsin kinase. J Biol Chem 1995; 270:18060-6.

8. Klenchin VA, Calvert PD, Bownds MD. Inhibition of rhodopsin kinase by recoverin. Further evidence for a negative feedback system in phototransduction. J Biol Chem 1995; 270:16147-52.

9. Calvert PD, Klenchin VA, Bownds MD. Rhodopsin kinase inhibition by recoverin. Function of recoverin myristoylation. J Biol Chem 1995; 270:24127-9.

10. Jones GJ. Light adaptation and the rising phase of the flash photocurrent of salamander retinal rods. J Physiol 1995; 487:441-51.

11. Gray-Keller MP, Detwiler PB. Ca2+ dependence of dark- and light-adapted flash responses in rod photoreceptors. Neuron 1996; 17:323-31.

12. Pepperberg DR, Cornwall MC, Kahlert M, Hofmann KP, Jin J, Jones GJ, Ripps H. Light-dependent delay in the falling phase of the retinal rod photoresponse. Vis Neurosci 1992; 8:9-18.

13. Pepperberg DR, Jin J, Jones GJ. Modulation of transduction gain in light adaptation of retinal rods. Vis Neurosci 1994; 11:53-62.

14. Pepperberg DR, Birch DG, Hofmann KP, Hood DC. Recovery kinetics of human rod phototransduction inferred from the two-branched alpha-wave saturation function. J Opt Soc Am A 1996; 13:586-600.

15. Hamer RD. Computational analysis of vertebrate phototransduction: combined quantitative & qualitative modeling of dark- and light-adapted responses in amphibian rods. Vis Neurosci 2000; 17:679-699.

16. Rieke F, Baylor DA. Single photon detection by rod cells of the retina. Reviews of Modern Physics 1998; 70:1027-36.

17. Forti S, Menini A, Rispoli G, Torre V. Kinetics of phototransduction in retinal rods of the newt Triturus cristatus. J Physiol 1989; 419:265-95.

18. Tamura T, Nakatani K, Yau KW. Calcium feedback and sensitivity regulation in primate rods. J Gen Physiol 1991; 98:95-130.

19. Lyubarsky A, Nikonov S, Pugh EN Jr. The kinetics of inactivation of the rod phototransduction cascade with constant Ca2+i. J Gen Physiol 1996; 107:19-34.

20. Nikonov S, Engheta N, Pugh EN Jr. Kinetics of recovery of the dark-adapted salamander rod photoresponse. J Gen Physiol 1998; 111:7-37.

21. Lamb TD, Pugh EN Jr. A quantitative account of the activation steps involved in phototransduction in amphibian photoreceptors. J Physiol 1992; 449:719-58.

22. Nakatani K, Yau KW. Calcium and light adaptation in retinal rods and cones. Nature 1988; 334:69-71.

23. Torre V, Forti S, Menini A, Campani M. Model of phototransduction in retinal rods. In: The Brain: Cold Spring Harbor Symposia on Quantitative Biology, Volume LV. Cold Spring Harbor (NY): Cold Spring Harbor Laboratory Press; 1991. p. 563-73.

24. Koutalos Y, Nakatani K, Yau KW. The cGMP-phosphodiesterase and its contribution to sensitivity regulation in retinal rods. J Gen Physiol 1995; 106:891-921.

25. Koutalos Y, Nakatani K, Tamura T, Yau KW. Characterization of guanylate cyclase activity in single retinal rod outer segments. J Gen Physiol 1995; 106:863-90.

26. Burkhardt DA. Light adaptation and photopigment bleaching in cone photoreceptors in situ in the retina of the turtle. J Neurosci 1994; 14:1091-105.

27. Fain GL, Lamb TD, Matthews HR, Murphy RL. Cytoplasmic calcium as the messenger for light adaptation in salamander rods. J Physiol 1989; 416:215-43.

28. Yau KW, Nakatani K. Light-induced reduction of cytoplasmic free calcium in retinal rod outer segment. Nature 1985; 313:579-82.

29. Matthews HR, Murphy RL, Fain GL, Lamb TD. Photoreceptor light adaptation is mediated by cytoplasmic calcium concentration. Nature 1988; 334:67-9.

30. Matthews HR, Fain GL, Murphy RL, Lamb TD. Light adaptation in cone photoreceptors of the salamander: a role for cytoplasmic calcium. J Physiol 1990; 420:447-69.

31. McCarthy ST, Younger JP, Owen WG. Dynamic, spatially nonuniform calcium regulation in frog rods exposed to light. J Neurophysiol 1996; 76:1991-2004.

32. Sampath AP, Matthews HR, Cornwall MC, Bandarchi J, Fain GL. Light-dependent changes in outer segment free-Ca2+ concentration in salamander cone photoreceptors. J Gen Physiol 1999; 113:267-77.

33. Gray-Keller MP, Detwiler PB. The calcium feedback signal in the phototransduction cascade of vertebrate rods. Neuron 1994; 13:849-61.

34. McCarthy ST, Younger JP, Owen WG. Free calcium concentrations in bullfrog rods determined in the presence of multiple forms of Fura-2. Biophys J 1994; 67:2076-89.

35. Pugh EN Jr, Nikonov S, Lamb TD. Molecular mechanisms of vertebrate photoreceptor light adaptation. Curr Opin Neurobiol 1999; 9:410-8.

36. Detwiler PB, Gray-Keller MP. The mechanisms of vertebrate light adaptation: speeded recovery versus slowed activation. Curr Opin Neurobiol 1996; 6:440-4.

37. Rispoli G. Calcium regulation of phototransduction in vertebrate rod outer segments. J Photochem Photobiol B 1998; 44:1-20.

38. Rebrik TI, Korenbrot JI. In intact cone photoreceptors, a Ca2+-dependent, diffusible factor modulates the cGMP-gated ion channels differently than in rods. J Gen Physiol 1998; 112:537-48.

39. Hackos DH, Korenbrot JI. Calcium modulation of ligand affinity in the cyclic GMP-gated ion channels of cone photoreceptors. J Gen Physiol 1997; 110:515-28.

40. Hsu YT, Molday RS. Modulation of the cGMP-gated channel of rod photoreceptor cells by calmodulin. Nature 1993; 361:76-9.

41. Hsu YT, Molday RS. Interaction of calmodulin with the cyclic GMP-gated channel of rod photoreceptor cells. Modulation of activity, affinity purification, and localization. J Biol Chem 1994; 269:29765-70.

42. Sagoo MS, Lagnado L. G-protein deactivation is rate-limiting for shut-off of the phototransduction cascade. Nature 1997; 389:392-5.

43. Gorczyca WA, Gray-Keller MP, Detwiler PB, Palczewski K. Purification and physiological evaluation of a guanylate cyclase activating protein from retinal rods. Proc Natl Acad Sci U S A 1994; 91:4014-8.

44. Dizhoor AM, Lowe DG, Olshevskaya EV, Laura RP, Hurley JB. The human photoreceptor membrane guanylyl cyclase, RetGC, is present in outer segments and is regulated by calcium and a soluble activator. Neuron 1994; 12:1345-52.

45. Calvert PD, Ho TW, LeFebvre YM, Arshavsky VY. Onset of feedback reactions underlying vertebrate rod photoreceptor light adaptation. J Gen Physiol 1998; 111:39-51.

47. Hodgkin AL, Nunn BJ. Control of light-sensitive current in salamander rods. J Physiol 1988; 403:439-71.

48. Cornwall MC, Matthews HR, Crouch RK, Fain GL. Bleached pigment activates transduction in salamander cones. J Gen Physiol 1995; 106:543-57.

49. Koch KW, Stryer L. Highly cooperative feedback control of retinal rod guanylate cyclase by calcium ions. Nature 1988; 334:64-6.

50. Miller JL, Korenbrot JI. Differences in calcium homeostasis between retinal rod and cone photoreceptors revealed by the effects of voltage on the cGMP-gated conductance in intact cells. J Gen Physiol 1994; 104:909-40.

46. Dizhoor AM, Olshevskaya EV, Henzel WJ, Wong SC, Stults JT, Ankoudinova I, Hurley JB. Cloning, sequencing, and expression of a 24-kDa Ca(2+)-binding protein activating photoreceptor guanylyl cyclase. J Biol Chem 1995; 270:25200-6.

51. Pugh EN Jr, Duda T, Sitaramayya A, Sharma RK. Photoreceptor guanylate cyclases: a review. Biosci Rep 1997; 17:429-73.

52. Fesenko EE, Kolesnikov SS, Lyubarsky AL. Induction by cyclic GMP of cationic conductance in plasma membrane of retinal rod outer segment. Nature 1985; 313:310-3.

53. Haynes LW, Kay AR, Yau KW. Single cyclic GMP-activated channel activity in excised patches of rod outer segment membrane. Nature 1986; 321:66-70.

54. Zimmerman AL, Baylor DA. Cyclic GMP-sensitive conductance of retinal rods consists of aqueous pores. Nature 1986; 321:70-2.

55. Watanabe S, Matthews G. Dose-response relation of cyclic GMP-activated channels in the retinal rod photoreceptor. Neurosci Res Suppl 1989; 10:S1-7.

56. Yau KW, Baylor DA. Cyclic GMP-activated conductance of retinal photoreceptor cells. Annu Rev Neurosci 1989; 12:289-327.

57. Lagnado L, Cervetto L, McNaughton PA. Calcium homeostasis in the outer segments of retinal rods from the tiger salamander. J Physiol 1992; 455:111-42.

58. Menini A, Rispoli G, Torre V. The ionic selectivity of the light-sensitive current in isolated rods of the tiger salamander. J Physiol 1988; 402:279-300.

59. Ratto GM, Payne R, Owen WG, Tsien RY. The concentration of cytosolic free calcium in vertebrate rod outer segments measured with fura-2. J Neurosci 1988; 8:3240-6.

60. Korenbrot JI. Ca2+ flux in retinal rod and cone outer segments: differences in Ca2+ selectivity of the cGMP-gated ion channels and Ca2+ clearance rates. Cell Calcium 1995; 18:285-300.

61. Miller JL, Korenbrot JI. In retinal cones, membrane depolarization in darkness activates the cGMP-dependent conductance. A model of Ca homeostasis and the regulation of guanylate cyclase. J Gen Physiol 1993; 101:933-60.

62. Detwiler PB, Gray-Keller MP. Some unresolved issues in the physiology and biochemistry of phototransduction. Curr Opin Neurobiol 1992; 2:433-8.

63. Sampath AP, Matthews HR, Cornwall MC, Fain GL. Bleached pigment produces a maintained decrease in outer segment Ca2+ in salamander rods. J Gen Physiol 1998; 111:53-64.

64. Younger JP, McCarthy ST, Owen WG. Weak adapting backgrounds reduce the resting level of cytosolic free calcium in rod photoreceptors. Invest Ophthalmol Vis Sci 1991; 32:907.

65. Younger JP, McCarthy ST, Owen WG. Light-dependent control of calcium in intact rods of the bullfrog Rana catesbeiana. J Neurophysiol 1996; 75:354-66.

66. Cobbs WH, Pugh EN Jr. Kinetics and components of the flash photocurrent of isolated retinal rods of the larval salamander, Ambystoma tigrinum. J Physiol 1987; 394:529-72.

67. Baylor DA, Lamb TD, Yau KW. Responses of retinal rods to single photons. J Physiol 1979; 288:613-34.

68. Hamer RD, Tyler CW. Does the saturation period of vertebrate photocurrent flash response reflect only rhodopsin lifetimes? Invest Ophthalmol Vis Sci 1996; 37:S811.

69. Hamer RD. Computational modeling of the full flash response dynamics of dark-adapted tiger salamander rod. Invest Ophthalmol Vis Sci 1998; 39:S955.

70. Hamer RD. How "signature" features in dark- & light-adapted photocurrent responses constrain models of vertebrate phototransduction. Invest Ophthalmol Vis Sci 1999; 40:S208.

71. Cornwall MC, Fain GL. Bleached pigment activates transduction in isolated rods of the salamander retina. J Physiol 1994; 480:261-79.

72. Fain GL, Matthews HR, Cornwall MC. Dark adaptation in vertebrate photoreceptors. Trends Neurosci 1996; 19:502-7.

73. Matthews HR, Cornwall MC, Fain GL. Persistent activation of transducin by bleached rhodopsin in salamander rods. J Gen Physiol 1996; 108:557-63.

74. Bownds MD, Arshavsky VY. What are the mechanisms of photoreceptor adaptation? Behav Brain Sci 1995; 18:415-424.

Typographical corrections
