Figure 5 of
Stenkamp, Mol Vis 4:26, 1998.Figure 5 of
Stenkamp, Mol Vis 4:26, 1998.
Figure 5. Double in situ hybridization of embryonic zebrafish (80 hpf) cryosections
(A) Section hybridized with dig-labeled IRBP cRNA (brown color product) and FL-labeled red cone opsin cRNA (blue color product). Photoreceptors are labeled with either IRBP cRNA only (brown cells indicated by small arrow) or by both IRBP and red cone opsin cRNAs (black cells indicated by small arrowheads); large arrowhead indicates IRBP-labeled RPE. (B) Section hybridized with dig-labeled IRBP cRNA (brown color product) and FL-labeled rod opsin (blue color product). Photoreceptors are labeled with either IRBP only (brown cells indicated by small arrow), or by rod opsin only (blue cells indicated by large arrow), or by both IRBP and rod opsin (black cells indicated by small arrowheads); large arrowhead indicates IRBP-labeled RPE. Scale bars = 50 µm.
