Figure 2 of Yoo, Mol Vis 2017; 23:933-943.


Figure 2. Retinal injury-induced inflammation is suppressed by SP. At 1 and 3 weeks post-dispase injection, serum was collected, and the cytokine profile was analyzed with enzyme-linked immunosorbent assay (ELISA). A,B: Tumor necrosis factor-alpha (TNF-α) and interleukin-10 (IL-10) in serum 1 week post-dispase injection. C,D: TNF-α and IL-10 in serum 3 weeks post-dispase injection. *p<0.05; ***p<0.001; n=8 mice per group.
