Figure 5 of Di Lauro, Mol Vis 2016; 22:243-253.


Figure 5. Neuroretina immunohistochemistry during the culture and coculture period. In the freshly isolated retina explants (A), RHO immunoreactivity (green) showed the normal appearance of rod outer segments (OS). At 9 days of neuroretina explants culture alone (B), RHO was scarcely detected, and the inner segments (IS) were not discernable. Photoreceptor nuclei appeared at the IS region (B, arrowhead). At 9 days in coculture with RPE cells (C), RHO was displaced to the short and swollen rod IS and to the outer nuclear layer (arrows). In the freshly isolated retina explants (D), CB (red) showed cone photoreceptors with normal morphology. At 9 days of neuroretina culture alone (E), cone morphology was markedly altered as revealed with CB immunostaining. At 9 days in coculture with the RPE (F), cone morphology underwent degeneration. In the freshly isolated retina explants (G), CRALBP (green) showed Müller cells with normal morphology. Reduced immunostaining for GFAP (red) was observed. At 9 days of neuroretina culture alone (H), GFAP was upregulated at the cytoplasm of glial cells, and GFAP-positive extensions formed a layered-like structure outside the retinal tissue (arrows). At 9 days in coculture with RPE (I), CRALBP was scarcely detected, and GFAP was reduced compared to explants cultured alone. GFAP-positive processes were present over the outer limiting membrane (arrows). OS=outer segments; IS=inner segments; ONL=outer nuclear layer; INL=inner nuclear layer; GCL=ganglion cell layer. Scale bars=10 μm.
