Figure 13 of Boatright, Mol Vis 2015; 21:40-60.


Figure 13. Qualitative variation in RPE sheets among different strains of mice. Each image represents a 75,000 square micron field of anti-ZO-1 stained RPE from three mouse genotypes, C57Bl/6J (wild type, WT), IRBP−/−, and rd8 at postnatal day (P)30 and P720. A: C57Bl/6J at P30. B: C57Bl/6J at P720. C: IRBP−/− at P30. D: IRBP−/− at P720. E: rd8 at P30. F: rd8 at P720.
