Figure 8. Representation of a 6.5 kb insertion in intron 1 of
Gpr179 identified with polymerase chain reaction using an intron-specific primer and subsequent Sanger sequencing. The schematic
indicates the presence of the mutation in intron 1 of
Gpr179. The sequence obtained with PCR with an intron-specific primer (
Gpr179 rev) was used to design the mutation-specific primer. All three
Gpr179 primers (
Table 1) were used for genotyping.
