Figure 5 of Oki, Mol Vis 2013; 19:2374-2384.


Figure 5. Morphologies of endothelial cells contracting vitreous explants from chicken embryos. Stereomicroscopic images of bEnd.3 cells on vitreous surface were taken after hematoxylin and eosin (H&E) staining at the indicated periods. The micrograph depicts cell morphology on the vitreous surface at the anterior (A) or the posterior region (B) and the magnified image is shown in (C) or (D), respectively. The magnified image (E or F) is the cell morphology on the vitreous surface at the anterior or the posterior region, respectively, at 6 h after cell adhesion. Scale bar=200 μm.
