Figure 2. Pedigree analysis and molecular study of Family 2. A: DNA sequencing chromatogram from heterozygous mutant of proband (II:1) showed missense mutation in codon 166 in which Arg
was replaced by Trp (R166W C>T; arrow indicates the position of nucleotide substitution). B: The Pedigree of Family 2 indicates two affected patients (arrow indicates the proband) as well as the segregation of p.R166W
in the family. The each family's member was presented by age (in years), genotype and topography images. Filled symbols show
KTCN patient while open symbols represent persons without clinical KTCN.
