Figure 10. Immunohistochemical
localization of retinal outer segment membrane protein 1 (Rom1) and
peripherin/rds (Prph2) in the retinas of 3-week-old Rom1+/+,
Rom1Rgsc1156/+, and Rom1Rgsc1156/Rgsc1156
mice. Rom1 immunoreactivity was decreased in the outer segments of the
heterozygotes (B) in comparison with wild-type mice (A),
and Rom1 immunoreactivity was markedly reduced in the homozygotes (C).
Prph2 immunoreactivity in the outer segment was also decreased (E,
F, G). No signals were detected in the retinas of wild-type mice
when peptide absorption tests were performed (D, H). The bar
represents 50 µm. GCL, IPL, INL, OPL, ONL, IS, OS, and RPE refer to
ganglion cell layer, inner plexiform layer, inner nuclear layer, outer
plexiform layer, outer nuclear layer, inner segment, outer segment, and
retinal pigment epithelium.
