Figure 5. Confocal double-label
immunocytochemical localization of Mel1a and Mel1b in Xenopus
corneal whole mounts. A: The specimen shown was obtained in the
mid-light period (12N). Both Mel1a (red) and Mel1b (green)
immunolabeling is present on the lateral plasma membrane appearing
mostly as the merged yellow fluorescence indicative of co-localization.
A significant amount of green Mel1b immunoreactivity is also present in
the cytoplasm. Arrows are provided as reference points to indicate the
same points on panel B. The inset illustrates the 72° rotation on the
x-axis of the image in A, indicating the orientation relative
to the viewer’s eye in B. B: Three-dimensional
reconstructions of confocal z-stacks of optical slices were rotated at
72° degrees on the x-axis to enable optimal viewing of the pattern of
immunolabeling. The rotated image shows that the Mel1a-Mel1b-labeled
cells are characterized by a broad band of merged yellow labeling,
interdigitating with a lesser amount of red Mel1a labeling. This
pattern of labeling suggests that a majority of Mel1a and Mel1b
receptors are located in very close proximity to each other on the
lateral membrane. The confocal images in both panels are comprised of
19 optical slices of 400 nm each in the z-series. The
magnification bar (B) represents 20 µm.
