Figure 7 of McGowan, Mol Vis 2007; 13:1984-2000.


Figure 7. Double labeling: nestin and telomerase

In the unwounded (A, B) and wounded (C) corneal sections, nestin is present in the trabecular meshwork and the transition zone, and telomerase is present in the trabecular meshwork, transition zone, and the corneal endothelium. Bright green indicates nestin; red indicates telomerase; and blue indicates cell nuclei from Hoechst stain. All sections shown are from a 38-year-old male. Control slides showed no reaction (D).

(269 K)

McGowan, Mol Vis 2007; 13:1984-2000 <http://www.molvis.org/molvis/v13/a224/>
©2007 Molecular Vision <http://www.molvis.org/molvis/>
ISSN 1090-0535
