Figure 6 of Valamanesh, Mol Vis 2007; 13:1746-1757.


Figure 6. No caspase-independent markers of apoptosis in triamcinolone treated ARPE-19 cells

A- G: Triamcinolone-treated (0.1 mg/ml in 1% ethanol) or control ARPE 19 cells were stained with DAPI or immunostained with anti-AIF or anti LEI/L-DNase II. No nuclear translocation of these apoptosis markers was seen, neither in cells with normal morphology, nor in cells with an altered nuclear morphology (A, white arrows). H-M: Induction of apoptosis with HMA was used as positive control and shows nuclear translocation of both LEI and AIF, both markers of caspase independent apoptosis. Sacle bar represents 20 μm.

(57 K)

Valamanesh, Mol Vis 2007; 13:1746-1757 <http://www.molvis.org/molvis/v13/a195/>
