Figure 3 of
Rezaie, Mol Vis 2007;
13:1446-1450.Figure 3 of
Rezaie, Mol Vis 2007;
13:1446-1450.
Figure 3. Expression of Optn mRNA at age 13.5 dpc in frontal section of the developing eye
A: Whole eye at magnification 200X. B: Lens (L), vitreous (V), and Retina (R) at 400X, C: Lens fibers (LF) and lens anterior epithelium (LE) at 400X, and D: Retina and optic nerve (ON) at 400X.
