Figure 5 of Nakazawa, Mol Vis 2006; 12:867-878.


Figure 5. Cellular source of cytokines after RD

Co-localization of IL-1β (A-C) and MCP-1 (D-F) immunoreactivity (red) with markers for astrocytes-GFAP (A-C), or Müller glial cells-glutamine synthetase (D-F; green). Arrows point to astrocytes in (A-C) or to Müller glial cells in (D-F).

(182 K)

Nakazawa, Mol Vis 2006; 12:867-878 <http://www.molvis.org/molvis/v12/a98/>
©2006 Molecular Vision <http://www.molvis.org/molvis/>
ISSN 1090-0535
