Figure 6 of Pendergrass, Mol Vis 2006; 12:712-724.


Figure 6.

Involution of surface LECs in cataractous old lens. A: DNA (only) view of LSCM projection section 72 μm below the anterior surface of the old cataractous rat lens shown in Figure 5 to better illustrate the LEC origin of DNA involutions (DNA, red). B: ROS expression (DHR, green) is shown for same LSCM frame. The dotted lines surround gaps in surface epithelium.

(94 K)

Pendergrass, Mol Vis 2006; 12:712-724 <http://www.molvis.org/molvis/v12/a80/>
©2006 Molecular Vision <http://www.molvis.org/molvis/>
ISSN 1090-0535
