Figure 6 of Tserentsoodol, Mol Vis 2006; 12:1319-33.


Figure 6. Immunohistochemical localization of CD36 in monkey retina

The vibrotome sections from monkey retina were processed for immunhistochemistry and imaged by fluorescent confocal microscopy (see Materials and Methods). Nuclei were stained with DAPI (blue) and immunoreactivity was detected using a Cy5 conjugated secondary antibodies (red). A: Immunoreactivity detected using an anti CD36 peptide AKENVTQDAEDNTVSF rabbit polyclonal antibody (Cayman Chemical, Ann Arbor, MI) at 1:50 dilution. B: No primary antibody control. C: CD36 immunoreactivity at higher magnification focusing on the photoreceptors and retinal pigment epithelium/choriocapillaris regions. D: CD36 immunoreactivity at higher magnification focusing on the OPL region. Images C and D are shown with the green channel to take advantage of the retinal autofluorescence and provide better structural definition. Capillaries in D were stained with isolectin IB4 (green). Scale bars were included with each image.

(164 K)

Tserentsoodol, Mol Vis 2006; 12:1319-33 <http://www.molvis.org/molvis/v12/a149/>
